HP Compaq tc4200

C–18 Maintenance and Service Guide
Screw Listing
Silver Phillips M2.0×4.0 Screw Locations
Table C-10
Silver Phillips PM2.0×4.0 Screw
Color Qty. Length Thread
Head
Width
Silver 6 4.0 mm 2.0 mm 4.0 mm
Where used:
1 One screw that secures the button board to the tablet PC (documented in
Section 6.16)
2 One screw that secures the top cover to the tablet PC (documented in
Section 6.18)
mm
