6–6 Maintenance and Service Guide
Removal and Replacement Procedures
4. Remove the battery pack by following these steps:
c. Turn the tablet PC upside down with the rear panel
toward you.
d. Slide the battery release latch 1 toward you. (The left side
of the battery pack disengages from the tablet PC.)
e. Lift the left side of the battery pack and swing it to the
right 2 to remove it.
Removing the Battery Pack
Reverse the above procedure to install the battery pack.
