Event log message Description Comments
●
XX=02: Magenta density-
measurement abnormality
●
XX=03: Yellow density-
measurement abnormality
3. Press the down arrow to highlight
PRINT QUALITY, and then press
the OK button.
4. Press the down arrow
to highlight
QUICK CALIBRATE NOW, and
then press theOK button.
54.0E.01 Media sensor replace
registration-second-transfer assembly
The registration unit is abnormal. Ensure the product is in a supported
environment. If the error persists, replace
the registration-second-transfer
assembly. See
Secondary transfer
assembly on page 186.
54.0E.02 Replace transfer kit The ITB unit is abnormal. Ensure the product is in a supported
environment. If the error persists, replace
the ITB.
Intermediate transfer belt (ITB)
on page 188.
54.0E.03 Media sensor clean
registration second-transfer assembly
The media-sensor window is
contaminated.
Clean the media-sensor window.
54.0F.XX
●
XX=00: Black misregistration is out
of range.
●
XX=01: Cyan misregistration is out
of range.
●
XX=02: Magenta misregistration is
out of range.
●
XX=03: Yellow misregistration is out
of range.
1.
Press the Menu
button.
2. Press the down arrow
to highlight
CONFIGURE DEVICE, and then
press the OK button.
3. Press the down arrow
to highlight
PRINT QUALITY, and then press
the OK button.
4. Press the down arrow
to highlight
FULL CALIBRATE NOW, and then
press the OK button.
54.14 CPR sensor abnormality 1.
Press the Menu
button.
2. Press the down arrow
to highlight
CONFIGURE DEVICE, and then
press the OK button.
3. Press the down arrow
to highlight
PRINT QUALITY, and then press
the OK button.
4. Press the down arrow
to highlight
FULL CALIBRATE NOW, and then
press the OK button.
5. If the error persists, replace the
CPR sensor assembly.
6. Replace the ITB. See
Intermediate
transfer belt (ITB) on page 188.
54.19 The ITB top sensor is abnormal. 1.
Press the Menu
button.
2. Press the down arrow
to highlight
CONFIGURE DEVICE, and then
press the OK button.
ENWW Event log messages 401
