* The Intel Q965 Express chipset includes a built-in Management Engine (ME), which allocates memory for manageability functions.
Management Engine memory is shared with system memory. If the PC contains a single DIMM, 8 MB of memory is pre-allocated for it at
system startup. If the PC contains two DIMMs, 16 MB of memory is pre-allocated. This memory is not made available to the operating
system, just as pre-allocated video memory is not available.
Memory Configurations –
One of the following
USDT SFF CMT
512-MB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 512) X X X
512-MB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 256) X X X
1-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 1GB) X X X
1-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 512) X X X
2-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 1GB) X X X
2-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (4 x 512) X X
3-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (3 x 1GB) X X X
4-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (4 x 1GB) X X
256-MB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (1 x 256) X X X
512-MB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (1 x 512) X X X
512-MB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 256) X X X
1-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (1 x 1GB) X X X
1-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 512) X X X
2-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 1GB) X X X
2-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (4 x 512) X X
3-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (3 x 1GB) X X X
4-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (4 x 1GB) X X
Expandability USDT SFF CMT
PCI slots Optional, requires PCI riser:
1 full-height (4.2"), length (6.6")
2 low-profile (2.5"), length (6.6")
standard;
2 full-height (4.2"), length (6.875")
via optional riser card.
NOTE: With riser card option, PCIe
x1 and PCIe x16 slots are not
accessible.
2 full-height (4.2"), length (13.4")
standard;
(2 additional full-height slots
available via optional PCI extender
card)
Max power per slot 25W 25W 25W
PCI Express x16 slot Optional, requires PCIe x16 riser:
1 low-profile (3.987"), length
(6.60")
1 low-profile (2.5"), length (6.6") 1 full-height (4.2"), length (10.5")
Max power per slot 25W 25W 75W
PCI Express x1 slot N/A 1 low profile (2.5"), length (6.6") 1 full-height (4.2"), length (13.4")
Max power per slot N/A 10W 10W
External Bays 1 Slimline (WxDxH):
128 x 127 x 12.7 mm
2 4
3.5" N/A 1 1
5.25" N/A 1 (length 8.189") 3 (2 – length 8.189", 1 – length
5.71")
QuickSpecs
HP Compaq dc7700 Business PC
Standard Features and Configurable Components
DA - 12543 Canada — Version 34 — October 29, 2008 Page 11
