HP Designjet 110plus Series - Page 29

HP Designjet 70/110plus Printer series—Quick Reference Guide
28
• Lift the small handle on the top and use it to pull the printhead vertically up and
out of the printer.
• Take the new printhead and remove the tape that protects its electrical contacts
and ink nozzles.
• Lower the new printhead into place and return the small handle to its lowered
position.
How do I replace printheads? (continued)
