Parts and Diagrams
hp designjet 120/120nr and 130/130nr printer service manual
Left Hand Assemblies
Left Hand Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 C7791-60141 1
Front Panel Assembly (Applicable to
DesignJet 120/120nr)
C7790-60445 1
Front Panel Assembly (Applicable to
DesignJet 130/130nr)
2 C8108-67038 1 LF Motor Assembly (Paper-Axis Motor)
3 C8108-67040 1 Ramp Drive Assembly
4 0515-2812 1 Screw
5 C8108-67042 1 Output Mechanism Support Assembly
6 0515-2812 2 Screw
7 C8108-67051 1 Encoder Disc
8 C7791-60143 1 Carriage Motor Assembly
9 0515-2812 2 Screw
10 C8108-67048 1 Output Belt
