Parts and Diagrams
hp designjet 120/120nr and 130/130nr printer service manual
Scan-Axis Assemblies
Scan-Axis Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1C7791-601421
Carriage Assembly (Includes Trailing Cable
& Belt) (Applicable to DesignJet 120/120nr)
C7791-60279 1
Carriage Assembly (Includes Trailing Cable
& Belt) (Applicable to DesignJet 130/130nr)
2C7791-601291
Tubes Assembly (Applicable to DesignJet
120/120nr)
C7791-60291 1
Tubes Assembly (Applicable to DesignJet
130/130nr)
3 0515-2675 3 Screw
4C7791-602051Encoder Strip
5 C7790-60104 1 Encoder Strip Holder
6 0515-2812 1 Screw
7 C7790-60124 1 Tube Holder
8 C7790-60125 1 Belt Tension Spring
9C7791-602121
Turnaround Assembly (Includes Belt Tension
Spring)
10 C7791-60233 1 Carriage Belt
To Next Page
