Parts and Diagrams
hp designjet 120/120nr and 130/130nr printer service manual
Top Paper Path Assemblies
Top Paper Path Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 C7791-60229 1 OOPS Sensor Kit
2C7791-602011
Feed Roller Assembly (Includes Encoder Disc
and Paper-Axis Motor Assembly)
3 C7791-60245 1 Starwheel Assembly
4 0515-2812 3 Screw
5 C7791-60144 1 Print Platen
6C7791-602201
Bypass Platen Kit
(Applicable to DesignJet
120/120nr)
C7791-60287 1
Bypass Platen Kit
(Applicable to DesignJet
130/130nr)
7C7796-600261Pivot Assembly
8 0515-2555 2 Screw
9C7791-602321Pick Cam
-C8108-670301
Miscellaneous Plastic Parts (includes Plift
Block, Pin Caber, Pick Cam, FDRLR Idler
Gear)
10 Q1292-00002 1 Bypass Platen Actuator and Spring
