2
Parts and Diagrams
hp designjet 120/120nr and 130/130nr printer service manual
Cover Assemblies (Applicable to DesignJet 120/120nr)
Cover Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1C7791-601371Left Cover
2 0515-2811 2 Screw
3C7791-601381Right Cover
4 0515-2812 2 Screw
5 C7790-60295 1 Filter Assembly
6 C7791-60256 1 Back Cover (Center Cover)
7 0515-2811 6 Screw
8 C7790-60119 1 Door Sensor Assembly
9 C7791-60130 1 Ink Cartridge Door (HP DesignJet 120)
C7791-60131 1 Ink Cartridge Door (HP DesignJet 120nr)
10 C7790-60106 1
Printhead Door Assembly (includes Ink
Cartridge Door Hinge)
11 C7791-60139 1 Access Door Assembly
12 C7791-60216 1 Rear Trim Kit (Applicable to DesignJet 120)
To Next Page
