Parts and Diagrams
hp designjet 120/120nr and 130/130nr printer service manual
Right Hand Assemblies
Right Hand Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1C7790-604191
Ink Supply Station Assembly (Applicable to
DesignJet 120/120nr)
C7790-60458 1
Ink Supply Station Assembly (Applicable to
DesignJet 130/130nr)
2 0515-2812 2 Screw
3C7790-601451ISS Bottom Foam
4 C7790-60144 1
ISS Rear Foam (Applicable to DesignJet
120/120nr)
C7790-60470 1
ISS Rear Foam (Applicable to DesignJet
130/130nr)
5C7791-601321
Electronics Module Assembly (Applicable to
DesignJet 120/120nr)
C7791-60208 1
Electronics Module Assembly (Applicable to
DesignJet 130/130nr)
6 0515-2599 2 Screw
7 C7790-60091 1 Power Supply Unit
8 0515-2599 2 Screw
9 C7790-60420 1
Service Station Assembly (Applicable to
DesignJet 120/120nr)
C7790-60476 1
Service Station Assembly (Applicable to
DesignJet 130/130nr)
10 C7791-60219 1 Cleanout Interconnect PCA
