HP Designjet 4500 Printer Series Service Manual
Using this Manual
Purpose
This Service Manual contains information necessary to test, calibrate and
service:
 HP Designjet 4500 printer (Model Q1271A)
 HP Designjet 4500ps printer (Model Q1272A)
 HP Designjet 4500 mfp (Model Q1276A)
For information about using these printers, refer to the corresponding User
and Quick Reference Guides.
Readership
The procedures described in this Service Manual are to be performed by HP
Certified service personnel only.
Part Numbers
Part Numbers for Printer options, accessories and service parts are located
in Chapter 7.
Conventions
A small arrow ⇒ is used to indicate other parts of the Service Manual where
you can find information related to the topic you are consulting.
In some sections of this Service Manual you may see images which include
parts of the HP Designjet 4000 Printer series; these areas of the image can
be ignored.

HP Designjet 4500 Series Specifications

General

Roll Feed	Yes
Cutter	Yes
Model	4500 series
Print technology	HP Thermal Inkjet
Media types supported	Bond, Coated, Photo
Maximum roll width	42 in
