11. Lift the loading table to ease the spindle into the printer.
CAUTION: To avoid trapping your fingers, do not push the roll with your hands.
If you regularly use different substrates, you can change rolls more quickly if you pre-load rolls of
different substrates on different spindles. Extra spindles are available for purchase.
Load a roll into the printer (automatically)
To start this procedure, you need to have a roll loaded on the spindle. See Load a roll onto the spindle
on page 23.
The normal minimum substrate width is 23 inches (584 mm). To load substrates down to a minimum
width of 10 inches (254 mm), go to the front panel and select the
icon, then select Substrate
handling options > Enable narrow substrate. With this option, print quality is not guaranteed.
TIP: To load a roll of textile material, see The loading accessory on page 50.
TIP: When loading very thin or very thick substrates, or substrates with a tendency to curl, you should
follow the manual loading procedure to reduce the risk of substrate jams and printhead crashes; see
Load a roll into the printer (manually) on page 30.
1.
At the printer's front panel, select the
icon, then select Substrate load > Load roll.
ENWW
Load a roll into the printer (automatically)
27
Handle the substrate
