HP DesignJet Series - Scan-Axis Assemblies Identification

6-16
Parts and Diagrams
HP Designjet Ultra Low End Printer Service Manual
Scan-Axis Assemblies
Scan-Axis Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 C7790-60278 1
Carriage Assembly (Includes Trailing Cable)
(Applicable to 10ps, 20ps and 50ps)
Q1293-60046 1
Carriage Assembly (Includes Trailing Cable)
(Applicable to 30 and 30n)
Q1292-60202 1
Carriage Assembly (Includes Trailing Cable)
(Applicable to 130 and 130nr)
Q6655-60121 1
Carriage Assembly (Includes Trailing Cable)
(Applicable to 70)
Q6656-60094 1
Carriage Assembly (Includes Trailing Cable)
(Applicable to 90, 90r)
C7796-60205 1
Carriage Assembly (Includes Trailing Cable)
(Applicable to 100, 100+, 110, 110+,
110+nr)
C7791-60142 1
Carriage Assembly (Includes Trailing Cable)
(Applicable to 120 and 120nr)
2 C7790-60112 1
Tubes Assembly
(Applicable to 10ps, 20ps
and 50ps)
Q1293-60065 1 Tubes Assembly (Applicable to 30 and 30n)
Q6655-60140 1 Tubes Assembly (Applicable to 70)
Q6656-60103 1 Tubes Assembly (Applicable to 90, 90r)
Q1292-60235 1
Tubes Assembly
(Applicable to 130 and
130nr)
C7796-60219 1
Tubes Assembly
(Applicable to 100, 100+,
110, 110+, 110+nr)
C7791-60129 1
Tubes Assembly
(Applicable to 120 and
120nr)
3 0515-2675 3 Screw
4 C7790-60203 1
Carriage Belt
(Applicable to 10ps, 20ps,
30, 30n, 50ps
Q6655-60069 1 Carriage Belt (Applicable to 70, 90, 90r)
C7791-60233 1
Carriage Belt
(Applicable to 100, 100+,
110, 110+, 110+nr, 120, 120nr, 130 and
130nr)
Q6655-60064 1 Carriage Belt (Applicable to 70, 90, 90r
5 C7790-60099 1
Encoder Strip (Applicable to 10ps, 20ps,
30, 30n, 50ps)
