HP DesignJet Series - Top Paper Path Assemblies

6-19
Parts and Diagrams
HP Designjet Ultra Low End Printer Service Manual
Top Paper Path Assemblies (1 of 2)
Applicable Designjets: 10ps, 20ps, 30, 30n, 50ps
Top Paper Path Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 C8108-67049 1 Inner Paper Guide
2 C8108-67043 1 Lower Paper Guide
3 C7790-60129 1
Feed Roller Assembly (Includes Encoder Disc)
4 C8108-67035 1 Pin Linkage Assembly
5 C8108-67033 1 Starwheel Assembly
6 0515-2812 2 Screw
7 C8108-67041 1 Print Platen (Includes Output Separator)
8 C8108-67039 1 Pick Roller Assembly
9 C8108-67029 1 Kicker Assembly
- C8108-67030 1
Miscellaneous Plastic Parts (includes Plift
B
l
ock, Pin Caber, Pick Cam, FDRLR Idler
Gear)
- Q1292-60209 1
OPPS Sensor Kit
