7-6
Removal and Installation
HP Designjet Ultra Low End Printer Service Manual
Front Cover (Applicability: 10ps, 20ps, 30, 30n, 50ps)
Removal
Switch off the product and remove the power cable.
1. Open the Access Cover.
2. Release the clips (from the inside) that
se
cure the Front Cover.
3. Remove the Front Cover from the Printer.
To Next Page
