5-15
Calibrations
HP Designjet Ultra Low End Printer Service Manual
Parts replacement and associated calibrations
Following the removal and replacement of some components, it is important
that calibrations are performed immediately afterwards. Shown below is a
table describing which parts require calibrations when they are replaced,
and the order in which you should perform the calibrations.
Description of
service part
Media
Advance
Calibration
PRS
Calibration
Printhead
Alignment
Print Platen SV 1 2
Pick Roller SV 1 2 3
Feed Roller 1 2 3
Inner Paper G SV 1 2 3
Carriage Belt SV
1
Lower Paper Guide Bits SV 1 2 3
Bypass Platen 1 2 3
Bypass Actuator 1 2 3
Carriage SV
1 2
Tubes SV 1
Pivot SV
1 2
Electronics Module
1
Disk Encoder 1 2
