6-5
Parts and Diagrams
HP Designjet Ultra Low End Printer Service Manual
Cover Assemblies
Cover Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 C7791-60300 1
Left Cover (Includes Front Panel Label)
(
A
pplicable to 130 & 130nr)
C7796-60018 1
Left Cover (Includes Front Panel Label)
(A
pplicable to 100, 100+,110, 110+,
110+nr)
C7791-60137 1
Left Cover (Includes Front Panel Label)
(
A
pplicable to 120 & 120nr)
Q6655-60091 1
Left Cover (Includes Front Panel Label)
(A
pplicable to 70)
Q6656-60062 1
Left Cover (Includes Front Panel Label)
(Ap
plicable to 90, 90r)
2 0515-2811 2 Screw
3 C7791-60286 1
Right Cover (Applicable to 90, 90r, 130 &
13
0nr
)
C7796-60064 1
Right Cover (Applicable to 70, 100,
100+,
110, 110+, 110+nr)
C7791-60311 1 Right Cover (Applicable to 120 & 120nr)
4 0515-2812 1 Screw
5 C7790-60295 1 Filter Assembly
6 C7791-60285
Back Cover (Center Cover) (Applicable to
13
0 & 13
0nr)
C7791-60310 1
Back Cover (Applicable to 100, 100+,
110,
110+, 110+nr, 120 &120nr)
Q6655-60092 1 Back Cover (Applicable to 70)
Q6656-60063 1 Back Cover (Applicable to 90, 90r)
7 0515-2811 4 Screw
8 Q1293-60054 1 Door Sensor Assembly
9 Q6655-60093 Ink Cartridge Door (Applicable to 70
)
Q
6656-60064 Ink Cartridge Door (Applicable to 90)
Q
6656-60079 Ink Cartridge Door (Applicable to 90r
)
C7791-60294 1 Ink Cartridge Door (Applicable to130)
C7
791-60295 1 Ink Cartridge Door (Applicable to130nr)
C7
796-60015 1 Ink Cartridge Door (Applicable to 100)
C7
796-60094
Ink Cartridge Door (Applicable to 100+)
