HP Designjet T1100 Series Service Manual

Table of Contents
2 HP Designjet T Series — Service Manual
Using this manual
Purpose
This Service Manual contains information necessary to test, calibrate and
service:
 HP Designjet T1100 Printer 24 inch (Model Q6683A)
 HP Designjet T1100 Printer 44 inch (Model Q6687A)
 HP Designjet T1100ps Printer 24 inch (Model Q6684A)
 HP Designjet T1100ps Printer 44 inch (Model Q6688A)
 HP Designjet T610 Printer 24 inch (Model Q6711A)
 HP Designjet T610 Printer 44 inch (Model Q6712A)
 HP Designjet T620 Printer 24 inch (Model CK835A)
 HP Designjet T1120 Printer 24 inch (Model CK837A)
 HP Designjet T1120 Printer 44 inch (Model CK839A)
 HP Designjet T1120ps Printer 24 inch (Model CK838A)
 HP Designjet T1120ps Printer 44 inch (Model CK840A)
For information about using these printers, refer to the corresponding User’s
Guide.
Readership
The procedures described in this Service Manual are to be performed by HP
Certified service personnel only.
Part numbers
Part numbers for printer options, accessories and service parts are located in
Chapter 5 Parts and Diagrams on page 5-1.
Conventions
Any text that uses the blue underlined format (except this one) is a link that
directs you to the page number of the reference. If you are viewing the
document as a PDF file, you can click on that link to be taken there directly.

HP Designjet T1100 Series Specifications

General

Print Technology	Thermal Inkjet
Media Thickness	Up to 31.5 mil
Line Accuracy	+/- 0.1%
Media Sizes Supported	A4, A3, A2, A1, A0
Connectivity	1 Fast Ethernet (10/100Base-T), 1 Hi-Speed USB, 1 EIO Jetdirect accessory slot
Memory	256 MB
Hard Disk	40 GB
Print Languages	HP-GL/2, HP-RTL, CALS G4
Media Types	Bond paper, Coated paper, Matte film, Photo paper, Tracing paper, Vellum
Guaranteed Minimum Line Width	0.1 mm
Ink Types	Dye-based (color), pigment-based (black)
