HP Designjet T1100

Print speed
3
Line drawings
4
Fast: 35 sec/page on D/A1, 70 D/A1 prints per hour (Economode on)
52 D/A1 prints per hour (Economode off)
Color images Fast: 445 ft
2
/hr (41 m 2/hr)
5
Best: 30 ft
2
/hr (2.8 m 2/hr)
6
Print resolution maximum 2400 x 1200 optimized dpi
Memory 256 MB standard memory, 40 GB hard disk
Media
Handling Roll feed, sheet feed
Types Bond and coated paper (bond, coated, heavyweight coated, super heavyweight
coated, super heavyweight plus matte, colored), photographic paper (satin, gloss,
semi-gloss, matte, high-gloss), technical paper (natural tracing, translucent bond, vellum),
film (clear, matte, polyester), backlit material, self-adhesive material (two-view cling,
indoor paper, polypropylene, vinyl)
Weight 60 to 328 g/m
2
Size: 24-inch models: 8.5- to 24-inch wide sheets, 11- to 24-inch rolls
44-inch models: 8.5- to 44-inch wide sheets, 11- to 44-inch rolls
Thickness Up to 31.5 mil
Maximum roll length 300 ft/91 m
Printing
Margins Roll: 0.2 x 0.2 x 0.2 x 0.2 in./5 x 5 x 5 x 5 mm (borderless on photo papers)
Sheet: 0.2 x 0.67 x 0.2 x 0.2 in./5 x 16.75 x 5 x 5 mm
Technology HP Thermal Inkjet
Ink cartridge colors Cyan, gray, magenta, matte black, photo black, yellow
Ink types HP Vivera inks
Ink drop 6 pl (cyan, magenta, photo black, gray), 9 pl (yellow, matte black)
Ink cartridge size 69 ml (photo black, cyan, magenta, yellow, gray)
130 ml (matte black, photo black, cyan, magenta, yellow, gray)
Nozzles 1056 per color
Maximum line width 0.002 in./0.0423 mm
Line accuracy +/- 0.1%
7
Maximum print length 300 ft/91 m (OS and application dependent)
Connectivity
Interfaces (standard) One 10/100/1000BT Ethernet RJ-45 port, one Hi-Speed USB 2.0 certified
port, one EIO Jetdirect accessory slot
Interfaces (optional) HP Jetdirect print servers
Print languages (standard) HP Designjet T1100 Printer: HP-GL2/RTL, CALS/G4, HP PCL3GUI
HP Designjet T1100ps Printer: Adobe PostScript, Adobe PDF 1.6, HP-GL2/RTL,
CALS/G4, TIFF, JPEG, HP PCL3GUI
Drivers (included) HP Designjet T1100 Printer: HP-GL/2, HP-RTL Windows drivers; Optimized
Windows driver for AutoCAD 2000 and higher; support for Citrix MetaFrame
environments; HP PCL3GUI driver for Mac OS X
HP Designjet T1100ps Printer: HP-GL/2, HP-RTL Windows drivers; PS Windows
drivers; Optimized Windows driver for AutoCAD 2000 and higher; support
for Citrix MetaFrame environments; PS driver for Mac OS X
Environmental ranges
Operating temperature 41 to 104° F/5 to 40° C
Recommended operating temperature 59 to 95° F/15 to 35° C (depending on paper type)
Storage temperature -13 to 131° F/-25 to 55° C
Operating humidity 20 to 80% RH
Acoustic
Sound pressure, active 44 dB(A)
Sound pressure, standby 29 dB(A)
Sound power, active 6.5 B(A)
Sound power, standby 4.4 B(A)
Power consumption
Maximum 200 watts
Powersave 27 watts
Off 0.1 watts
Power requirements Input voltage (auto-ranging): 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz), 2 amp max
Certification
Safety United States and Canada (CSA certified), EU (LVD and EN60950-1 compliant), Russia
(GOST), Singapore (PSB), China (CCC), Argentina (IRAM), Mexico (NYCE)
Electromagnetic Compliance for Class B products: EU (EMC Directive), United States (FCC Rules), Canada
(DoC), Australia (ACA), New Zealand (MoC), China (CCC), Japan (VCCI); Certified as
Class A product: Korea (MIC), Taiwan (BSMI)
Environmental ENERGY STAR
®
qualified models; see: www.hp.com/go/energystar, WEEE, RoHS
Warranty One-year, next business day, on-site warranty
HP Care Pack Services H4518E HP Onsite Installation with Network Configuration
UG723E HP 3-Year Next Business Day Onsite Service
UG724E HP 4-Year Next Business Day Onsite Service
UG725E HP 5-Year Next Business Day Onsite Service
UG728PE HP 1-Year Post-Warranty Next Business Day Service
For more information, visit our website at www.hp.com/go/designjetT1100
HP Designjet T1100 Printer series
Technical specifications
Recommended system requirements
Macintosh Mac OS X v 10.2, Mac OS X v 10.3,
Mac OS X v 10.4 or higher; PowerPC G4,
G5, or Intel
®
Core Processor; 1 GB RAM; 2 GB
available hard disk space
Windows Windows 2000: Intel Pentium
®
III (733 MHz),
512 MB RAM, 2 GB available hard disk space;
Windows XP Home, Windows XP Professional:
Intel Pentium IV (1 GHz), 512 MB RAM, 2 GB
available hard disk space
Dimensions (w x d x h)
Printer 24-inch models:
49.7 x 26 x 41.2 in./1262 x 661 x 1047 mm
44-inch models:
69.7 x 26 x 41.2 in./1770 x 661 x 1047 mm
Shipping 24-inch models:
57.9 x 30.7 x 29.1 in./1470 x 780 x 740 mm
44-inch models:
77.3 x 30.7 x 30.7 in./1965 x 780 x 780 mm
Weight
Printer 24-inch models: 143 lb/65 kg
44-inch models: 189 lb/86 kg
Shipping 24-inch models: 225 lb/102 kg
44-inch models: 271 lb/123 kg
What’s in the box
24-inch models: Printer, printheads (3 x 2 colors each), introductory ink cartridges,
coated paper sample roll (24 in. x 25 ft), stand, rear tray (24 in.), 3-inch spindle
adaptor kit, quick reference guide, setup poster, legal document, doc and drivers DVD,
Autodesk Design Review CD, customer service guide, interface cable, power cord
44-inch models: Printer, printheads (3 x 2 colors each), introductory ink cartridges,
coated paper sample roll (24 in. x 25 ft), stand, rear tray (44 in.), 3-inch spindle adaptor
kit, quick reference guide, setup poster, legal document, doc and drivers DVD, Autodesk
Design Review CD, customer service guide, interface cable, power cord
Ordering information
Product
Q6683A HP Designjet T1100 24-inch Printer
Q6684A HP Designjet T1100ps 24-inch Printer
Q6687A HP Designjet T1100 44-inch Printer
Q6688A HP Designjet T1100ps 44-inch Printer
Accessories
Q6700A HP Designjet Zx100/Tx100/Tx10 24-inch Spindle
Q6709A HP Designjet Tx100/Tx10 44-inch Spindle
J7934G HP Jetdirect 620n Fast Ethernet Print Server
J7961G HP Jetdirect 635n IPv6/IPsec Print Server
J7997G HP Jetdirect 630n IPv6 Gigabit Print Server
Printheads
C9380A HP 72 Gray and Photo Black Printhead
C9383A HP 72 Magenta and Cyan Printhead
C9384A HP 72 Matte Black and Yellow Printhead
Ink cartridges
C9397A HP 72 69-ml Photo Black Ink Cartridge
C9398A HP 72 69-ml Cyan Ink Cartridge
C9399A HP 72 69-ml Magenta Ink Cartridge
C9400A HP 72 69-ml Yellow Ink Cartridge
C9401A HP 72 69-ml Gray Ink Cartridge
C9403A HP 72 130-ml Matte Black Ink Cartridge
C9370A HP 72 130-ml Photo Black Ink Cartridge
C9371A HP 72 130-ml Cyan Ink Cartridge
C9372A HP 72 130-ml Magenta Ink Cartridge
C9373A HP 72 130-ml Yellow Ink Cartridge
C9374A HP 72 130-ml Gray Ink Cartridge
Media supplies
Q6627A HP Super Heavyweight Plus Matte Paper 36 in. x 100 ft/914 mm x 30.5 m
Q6628A HP Super Heavyweight Plus Matte Paper 42 in. x 100 ft/1067 mm x 30.5 m
C6030C HP Heavyweight Coated Paper 36 in. x 100 ft/914 mm x 30.5 m
C6569C HP Heavyweight Coated Paper 42 in. x 100 ft/1067 mm x 30.5 m
Q1956A HP Heavyweight Coated Paper 42 in. x 225 ft/1067 mm x 67.5 m
C6019B HP Coated Paper 24 in. x 150 ft/610 mm x 45.7 m
C6020B HP Coated Paper 36 in. x 150 ft/914 mm x 45.7 m
C6980A HP Coated Paper 36 in. x 300 ft/914 mm x 91.4 m
C6035A HP Bright White Inkjet Bond Paper 24 in. x 150 ft/610 mm x 45.7 m
C6036A HP Bright White Inkjet Bond Paper 36 in. x 150 ft/914 mm x 45.7 m
C6810A HP Bright White Inkjet Bond Paper 36 in. x 300 ft/914 mm x 91.4 m
Q1397A HP Universal Inkjet Bond Paper 36 in. x 150 ft/914 mm x 45.7 m
C3868A HP Natural Tracing Paper 36 in. x 150 ft/914 mm x 45.7 m
C3875A HP Clear Film 36 in. x 75 ft/914 mm x 22.9 m
51642B HP Matte Film 36 in. x 125 ft/914 mm x 38.1 m
Q1427A HP Universal High-gloss Photo Paper 36 in. x 100 ft/914 mm x 30.5 m
Q1421A HP Universal Semi-gloss Photo Paper 36 in. x 100 ft/914 mm x 30.5 m
Q8834A HP Self-adhesive Gloss Polypropylene 36 in. x 75 ft/914 mm x 22.9 m
More HP media sizes and weights available at www.hp.com/go/designjet/supplies
4AA1-1499ENUC Rev. 2, February 2008
3
Mechanical printing time.
4
Printed on plain media.
5
Printed on coated media. Measured on a 44-inch model.
6
Printed on glossy media. Measured on a 44-inch model.
7
±0.1% of the specified vector length or ±0.1 mm (whichever is greater) at 23° C (73° F), 50-60% relative humidity, on E/A0 printing material in Best or Normal mode with HP Matte Film.
