6-10 HP Designjet T Series — Service Manual
Removal and Installation
Bin Assembly
Removal
1. Lay out the components of the basket.
2. Fit the basket supports to the stand legs,
one to each leg.
3. Fit the two short tubes to the printer’s feet,
one on the front of each foot. Each tube
should click into place.
Switch off the printer and remove the power cable.
