HP Designjet T Series — Service Manual 6-11
Removal and Installation - Bin Assembly
4. Attach the basket’s front tubes to the two
short tubes on each foot.
5. Rest the baskets rear tubes on the supports
that you have just fitted to each leg of the
stand.
6. The basket is now complete.
