6-32 HP Designjet T Series — Service Manual
Removal and Installation
8. Use a flat bladed screwdriver to unclip the
two attachment clips of the Formatter
Housing.
9. Lift the Formatter Housing out of the printer.
10. Remove one T-15 screw that secures the
Left Cover (top rear, accessible under the
Formatter Housing).
To Next Page
