HP Designjet T Series — Service Manual 6-33
Removal and Installation - Left Cover
11. Remove one T-15 screw that secures the
Left Cover (bottom rear).
12. Remove one T-15 screw that secures the
Left Cover (bottom rear).
13. Remove one T-15 screw that secures the
Left Cover (bottom front, accessible under
Front Cover).
To Next Page
