HP Designjet T1100

HP Designjet T Series — Service Manual 6-51
Removal and Installation - Top Cover
9. Carefully pull the attachment clip forward
until you can lift the bottom left corner of
the Top Cover approximately 10 mm.
10. Remove the front T-15 screw that secures
the front left side of the Top Cover to the
printer.
11. Carefully pull the attachment clip forward
until you can lift the bottom left corner of
the Top Cover approximately 10 mm.
1
2
1
2
