HP Designjet T1100

6-62 HP Designjet T Series — Service Manual
Removal and Installation
5. Disconnect the Aerosol Fan Assembly
inline connector.
6. Disconnect connector from the Primer
Motor and Primer Sensor.
7. Unroute the cables disconnected in steps 4
and 5 from the two cable clamps.
