HP Designjet T Series — Service Manual 6-65
Removal and Installation - Service Station (T1120/T1120ps)
Service Station (T1120/T1120ps)
Removal
1. Remove the Right Cover on page 6-27.
2. Disconnect the two lower connectors.
3. Unsnap the clamp from the bottom of the
metal sideplate.
4. Remove the grounding cable attachment
screw from the metal sideplate.
Switch off the printer and remove the power cable.
