6-66 HP Designjet T Series — Service Manual
Removal and Installation
5. Disconnect connector from the Primer
Motor and Primer Sensor.
6. Unroute the cables disconnected in steps 4
and 5 from the two cable clamps.
7. Loosen the T-10 uncapping screw
sufficiently so you can manually move the
Carriage Assembly in step 8.
