HP Designjet T Series — Service Manual 6-155
Removal and Installation - Line Sensor (T1100/T1100ps/T610)
15. Remove the large cover of the Carriage
PCA.
16. Disconnect the Line Sensor electrical
connection from the Carriage PCA.
17. Carefully unroute the Line Sensor cable
from the Carriage Assembly.
To Next Page
