HP Designjet T Series — Service Manual 6-182
Removal and Installation - Carriage PCA (T1120/T1120ps)
17. Press the locking clip to release the
Carriage Assembly PCB from the carriage.
18. Remove the Carriage PCA from the
carriage.
When you finish installing or replacing this component, you must perform the
necessary Service Calibrations. To find which calibrations you must perform,
see Service Calibration Guide to Removal and Installation
on page 6-5.
