HP Designjet T1100

HP Designjet T Series — Service Manual 6-183
Removal and Installation - Left Ink Supply Station
Left Ink Supply Station
Removal
1. Remove the Left Cover on page 6-30.
2. Remove two T-10 screws that secure the Left
Side Plate of the Left Ink Supply Station.
3. Remove the Left Side Plates of the Left Ink
Supply Station.
4. Remove two T-10 screws that secure the
Right Side Plate of the Left Ink Supply
Station.
Switch off the printer and remove the power cable.
