HP Designjet T Series — Service Manual 6-185
Removal and Installation - Left Ink Supply Station
8. Remove the two T-15 screws that secure the
Left Ink Supply Station to the printer.
9. Disconnect the three connectors from the
Left Ink Supply Station.
If you need to change the ISS
Harness Cable, make sure you
keep the previously used
plastic connector. The new
cable will arrive with a female
end, which you will replace
with the existing male end.
10. Unroute the three cables from the Left Ink
Supply Station.
To Next Page
