HP Designjet T Series — Service Manual 6-191
Removal and Installation - Ink Supply Tubes (T1100/T1100ps/T610)
16. Remove two T-10 screws that secure the left
Side Plate of the Left Ink Supply Station.
17. Remove the left Side Plate of the Left Ink
Supply Station.
18. Remove two T-10 screws that secure the
right Side Plate of the Left Ink Supply
Station.
