HP Designjet T1100

HP Designjet T Series — Service Manual 6-202
Removal and Installation - Electronics Module Main PCA and PSU (T1100/T1100ps/T610)
Electronics Module Main PCA and PSU (T1100/T1100ps/
T610)
Removal
1. Remove the Left Cover on page 6-30.
2. Disconnect all the connectors on the
Electronics Module.
3. Unroute all the cables disconnected in the
previous step.
4. Remove two T-15 screws that secure the
Electronics Module to the Printer.
Switch off the printer and remove the power cable.
