HP Designjet T1100

HP Designjet T Series — Service Manual 6-201
Removal and Installation - Formatter
3. Lift the Formatter out of the printer.
When you install a new
formatter follow the
instructions provided on the
Flyer that accompanies it to set
up the printer.
Remove the Hard Disc Drive (T1120/T1120ps ONLY)
4. Remove the four crosstread screws that
secure the Hard Disc Drive from behind.
5. Turn the Formatter to the opposite side.
6. Disconnect and remove the Hard Disc
Drive.
Take care not to damage the
Formatter components under
the Hard Disc Drive when you
remove it.
