HP Designjet T Series — Service Manual 6-206
Removal and Installation - Electronics Module Main PCA and PSU (T1120/T1120ps)
5. Remove one T-15 screw that secures the
Electronics Module to the Printer.
6. Remove one T-15 screw that secures the
Electronics Module to the Printer.
7. Remove two T-15 screws that secure the
Electronics Module to the Printer.
To Next Page
