HP Designjet T Series — Service Manual 6-219
Removal and Installation - Media Advance Drive
7. Grip the motor housing of the Media
Advance Drive and gently pull it towards
you sufficiently to allow you disengage the
Media Advance Drive from printer.
8. Carefully lift the Media Advance Drive out
of the printer.
To Next Page
