HP Designjet T Series — Service Manual 6-226
Removal and Installation - Media Advance Roller (T1100/T1100ps/T610 ONLY)
15. Remove four T-15 screws that secure the
Media Advance Roller left support to the
printer.
16. Remove the Media Advance Roller left
support from the printer.
17. Remove one T-15 screw that secures the
Media Advance Roller center support
locking plate.
