HP Designjet T120 Series

HP Designjet T120 ePrinter series
Technical specifications
Print
Line Drawings
70 sec/page, 40 A1 prints per hour
Colour images
22.4 m²/hr on coated media; 2.9 m²/hr on glossy media
Print resolution
Up to 1200 x 1200 optimized dpi
Margins (top x bottom x left x right)
Roll: 5 x 5 x 5 x 5 mm
Sheet: 5 x 17 x 5 x 5 mm
Technology
HP Thermal Inkjet
Ink types
Dye-based (C, M, Y); pigment-based (K)
Ink colours
4 (cyan, magenta, yellow, black)
Ink drop
5.5 pl (C, M, Y); 12 pl (K)
Print cartridge volume delivered
HP 711 Ink Cartridge: black (80 ml); black (38 ml); cyan, magenta, yellow (29 ml)
Print head nozzles
1376
Print heads
1 (cyan, magenta, yellow, black)
Line accuracy
+/- 0.1%
Line accuracy note: +/- 0.1% of the specified vector length or +/- 0.2 mm
(whichever greater) at 23ºC, 50-60% relative humidity, on A0 printing material in
Best or Normal mode with HP Matte Film and Original HP inks.
Minimum line width
0.04 mm (HP-GL/2 addressable)
Guaranteed minimum line width
0.07 mm (ISO/IEC 13660:2001(E))
Maximum print length
45.7 m
Maximum print weight
4.1 kg
Maximum optical density
8 L* min/2.10 D
Media
Handling
Sheet feed; roll feed; input tray; automatic cutter
Types
Bond and coated paper (bond, coated, heavyweight coated, recycled, plain,
bright white), technical paper (natural tracing, vellum), film (clear, matte),
photographic paper (satin, gloss, semigloss, premium, polypropylene),
self-adhesive (adhesive, polypropylene)
Weight
60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (input tray)
Size
CQ891A
Input tray: 210 x 279 to 330 x 482 mm; manual feed: 330 x 482 to 610 x 1897
mm; roll: 279 to 610 mm
Thickness
Up to 0.3 mm
Memory
Standard
256 MB
Hard disk
None
Connectivity
Interfaces (standard)
Fast Ethernet (100Base-T); Hi-Speed USB 2.0 certified; WiFi
Interfaces (optional)
Compatible HP Jetdirect print servers
Print languages (standard)
HP PCL 3 GUI, JPEG
Drivers included
HP PCL 3 GUI driver for Mac OS X and Windows®
Environmental ranges
Operating temperature
5 to 40ºC
Storage temperature
-25 to 55ºC
Operating humidity
20 to 80% RH
Storage humidity
0 to 95% RH
Acoustic
Sound Pressure
48 dB(A), < 16 dB(A) (standby)
Sound Power
6.5 B(A), < 3.4 B(A) (standby)
Dimensions (w x d x h)
Printer
987 x 530 x 285 mm
Packaged
1141 x 620 x 415 mm
Weight
Printer
25.5 kg
Packaged
30 kg
Power consumption
Maximum
< 35 watts (printing), < 4.5 watts (sleep), < 0.3 watts (standby)
Power requirements
Input voltage (auto ranging): 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz),
1200 mA max
What's in the box
CQ891A
HP Designjet T120 ePrinter; printhead; spindle; introductory ink cartridges;
quick reference guide; setup poster; startup software; power cord
Certification
Safety
EU (LVD and EN 60950-1 compliant); Russia (GOST)
Electromagnetic
Compliant with Class B requirements, including: EU (EMC/R&TTE Directives)
Environmental
ENERGY STAR®; WEEE; EU RoHS; REACH; EuP; FEMP; EPEAT Bronze
ENERGY STAR
Yes
Warranty
One-year limited hardware warranty. Warranty and support options vary by
product, country and local legal requirements.
Ordering information
Product
CQ891A
HP Designjet T120 610mm ePrinter
Accessories
B3Q35A
HP Designjet T120 24-in Stand
B3Q36A
HP Designjet T120/T520 24-in Spindle
Ink supplies
CZ129A
HP 711 38-ml Black Ink Cartridge
CZ130A
HP 711 29-ml Cyan Ink Cartridge
CZ131A
HP 711 29-ml Magenta Ink Cartridge
CZ132A
HP 711 29-ml Yellow Ink Cartridge
CZ133A
HP 711 80-ml Black Ink Cartridge
CZ134A
HP 711 3-pack 29-ml Cyan Ink Cartridges
CZ135A
HP 711 3-pack 29-ml Magenta Ink Cartridges
CZ136A
HP 711 3-pack 29-ml Yellow Ink Cartridges
C1Q10A
HP 711 Designjet Printhead Replacement Kit
Service & support
U1V95E - HP 3 year Next Business Day Designjet T120 24-in Hardware Support
U1W29E - HP 3 year 4-hour 13x5 Designjet T120 24-in Hardware Support
U1W34PE - HP 1 year Post Warranty Next Business Day Designjet T120 24-in Hardware Support
U6A00PE - HP 1 year Post Warranty 4-hour 13x5 Designjet T120 24-in Hardware Support
*U1W29E/U6A00PE - Please check availability at country level.
HP Designjet Support Services offer solutions for business critical environments - installation, extended support and
maintenance, as well as variety of value added services. For more information, please visit hp.com/go/designjet/support.
Use Original HP inks and printheads to experience consistent high quality and reliable performance that enable less
downtime. For more information, visit hp.com/go/OriginalHPinks.
For the entire HP Large Format Printing Materials portfolio, please see globalBMG.com/hp.
For more HP Large Format Media substrates and sizes please visit us online at: http://www.hp.com/go/designjet/supplies
