HP Designjet T1200 HD Multifunction Printer series
Technical specifications
Print
Line Drawings 28 sec/page, 103 A1 prints per hour
Colour images 41 m²/hr on coated media; 6.7 m²/hr on glossy media
Print speed 103 A1 prints per hour
Print resolution Up to 2400 x 1200 optimised dpi from 1200 x 1200 input dpi with maximum detail selected
Margins (top x bottom x left x right) Roll: 5 x 5 x 5 x 5 mm (borderless on photo papers)
Sheet: 5 x 17 x 5 x 5 mm
Technology HP Thermal Inkjet
Ink types Dye-based (C, M, Y, G, PK); pigment-based (MK)
Ink colours 6 (cyan, grey, magenta, matte black, photo black, yellow)
Ink drop 6 pl (C, M, PK, G), 9 pl (Y, MK)
Print head nozzles 1056
Print heads 3 (matte black and yellow, magenta and cyan, photo black and grey)
Line accuracy +/- 0.1%
Minimum line width 0.02 mm (HP-GL/2 addressable)
Guaranteed minimum line width 0.06 mm (ISO/IEC 13660:2001(E))
Maximum print length 91 m (application dependent)
Maximum optical density 2.15 maximum black optical density (6 L*min)
Scan
Scan speed Colour (200 dpi/400 dpi Turbo): up to 5.1 cm/sec; Black and white (200 dpi/400 dpi Turbo): up to
15.2 cm/sec
Scan resolution, hardware Up to 600 x 600 dpi
Scan resolution, optical Up to 600 dpi
Scan size (flatbed), maximum 1067-mm wide
Copy
Copy resolution Up to 9600 dpi
Copy reduce / enlarge settings 1 to 10000%
Maximum number of copies Up to 1000 copies
Media
Handling Printer: sheet feed, two automatic roll feeds, automatic roll-switching, automatic cutter; scanner:
straight-through scan paper path for sheet and cardboard originals
Types Printer: bond and coated paper (bond, coated, heavyweight coated, super heavyweight plus
matte, coloured), technical paper (natural tracing, translucent bond, vellum), film (clear, matte,
polyester), photographic paper (satin, gloss, semi-gloss, matte, high-gloss), backlit,
self-adhesive (two-view cling, indoor paper, polypropylene, vinyl), scanner: non-abrasive paper,
vellum, Mylar, sepia, blueprints, plastic, film, plastic laminate, foam board, cardboard (No
plywood, stone plates, metal plates or abrasive, dirty, rough, sharp edged, metal clamped, or
burned surfaces or transparencies)
Weight 60 to 328 g/m²
Size 210 x 279 to 1118 x 1676 mm
Thickness Up to 0.8 mm
Memory
Standard Printer: 32 GB (virtual); scanner: 1 GB
Connectivity
Interfaces (standard) Printer: Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, EIO Jetdirect accessory slot; scanner:
Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, FireWire (IEEE-1394a compliant)
Interfaces (optional) HP Jetdirect internal print servers
Print languages (standard) Adobe PostScript® 3, Adobe PDF 1.7, TIFF, JPEG, HP-GL/2, HP-RTL, CALS G4, HP PCL 3 GUI
Drivers included HP-GL/2, HP-RTL, PostScript® drivers for Windows (optimised for AutoCAD 2000 and higher);
PostScript® drivers for Mac OS X and Linux; support for Citrix® XenApp and Citrix® XenServer
environments
Operating systems compatibility
Windows® 7 Home Premium/Professional/Ultimate; Windows Vista® Home
Premium/Business/Ultimate; Microsoft® Windows® XP (32-bit / 64-bit) Home/Professional,
Server 2003 (32-bit / 64-bit), Server 2008 (32-bit / 64-bit); Novell® NetWare 5.x, 6.x; Mac OS X
v10.4, v10.5, v10.6, Citrix® XenApp, Citrix® XenServer
Recommended system requirements
Mac Mac OS X v10.4, v10.5: PowerPC G3 or Intel® Core processor; 256 MB RAM; 1 GB available hard
disk space; Mac OS X v10.6: Mac computer with Intel® Core processor; 1 GB RAM; 2 GB available
hard disk space
Windows Windows® 7: 32-bit (x86) or 64-bit (x64) processor (1 GHz), 1 GB RAM (32-bit) or 2 GB RAM
(64-bit), 2 GB available hard disk space; Windows Vista® Home Premium/Business/Ultimate:
32-bit (x86) or 64-bit (x64) processor (1 GHz), 1 GB RAM, 2 GB available hard disk space;
Microsoft® Windows® XP Home/Professional (SP2 or higher): Intel® Pentium® family or AMD
K6™/Athlon™/Duron™ family (1 GHz), 512 MB RAM, 2 GB available hard disk space
Environmental ranges
Operating temperature 5 to 40ºC
Recommended operating temperature 15 to 35º C (depending on paper type)
Storage temperature -25 to 55ºC
Operating humidity 20 to 80% RH
Recommended operating humidity 20 to 80% RH (depending on paper type)
Storage humidity 0 to 95% RH
Acoustic
Sound Pressure 47 dB(A)
Sound Power 6.3 B(A)
What's in the box
CQ653A Printer; printheads; introductory ink cartridges; 111.8 cm stand; 111.8 cm spindle; quick
reference guides; setup posters; Serif PosterDesigner Pro for HP poster; start-up software;
scanner; touchscreen (panel PC); scanner documentation software; system recovery software;
customer service guide; USB cable; FireWire cable; Ethernet cable; power cords
CQ653B Printer; printheads; introductory ink cartridges; 111.8 cm stand; 111.8 cm spindle; quick
reference guides; setup posters; Serif PosterDesigner Pro for HP poster; start-up software;
scanner; touchscreen (panel PC); scanner documentation software; system recovery software;
customer service guide; USB cable; FireWire cable; Ethernet cable; power cords
Dimensions (w x d x h)
Printer 1900 x 1000 x 1600 mm
Packaged 1930 x 766 x 1529 mm
Weight
Printer 200 kg
Packaged 280 kg
Power consumption
Maximum Printer: 120 watt, scanner: 300 watts maximum (active); printer: < 7 watts / < 25 watts with
embedded DFE (powersave); 65.3 watts (standby); 3.6 watts
Power requirements Input voltage (auto ranging) printer: 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz), 2 A max;
scanner: 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz), 5 A max
Certification
Safety EU (LVD and EN60950-1 compliant); Russia (GOST)
Electromagnetic Compliance for Class A ITE products: EU (EMC Directive)
Environmental EU RoHS; REACH; WEEE
ENERGY STAR No
Warranty
Two-year limited warranty. Warranty and support options vary by product, country and local
legal requirements.
Ordering information
Product
CQ653A HP Designjet T1200 HD Multifunction Printer
CQ653B HP Designjet T1200 HD Multifunction Printer
Accessories
Q6709A HP Designjet 1118mm Roll Feed Spindle
Ink supplies
C9380A HP 72 Gray and Photo Black Printhead
C9383A HP 72 Magenta and Cyan Printhead
C9384A HP 72 Matte Black and Yellow Printhead
C9397A HP 72 69-ml Photo Black Ink Cartridge
C9398A HP 72 69-ml Cyan Ink Cartridge
C9399A HP 72 69-ml Magenta Ink Cartridge
C9400A HP 72 69-ml Yellow Ink Cartridge
C9401A HP 72 69-ml Grey Ink Cartridge
C9403A HP 72 130-ml Matte Black Ink Cartridge
C9370A HP 72 130-ml Photo Black Ink Cartridge
C9371A HP 72 130-ml Cyan Ink Cartridge
C9372A HP 72 130-ml Magenta Ink Cartridge
C9373A HP 72 130-ml Yellow Ink Cartridge
C9374A HP 72 130-ml Grey Ink Cartridge
CH575A HP 726 300-ml Matte Black Designjet Ink Cartridge
Media supplies
C6030C HP Heavyweight Coated Paper-914 mm x 30.5 m (36 in x 100 ft)
C6020B HP Coated Paper-914 mm x 45.7 m (36 in x 150 ft)
C6036A HP Bright White Inkjet Paper-914 mm x 45.7 m
Q1397A HP Universal Bond Paper-914 mm x 45.7 m (36 in x 150 ft)
C3868A HP Natural Tracing Paper-914 mm x 45.7 m (36 in x 150 ft)
C3875A HP Clear Film-914 mm x 22.9 m (36 in x 75 ft)
Q1421A HP Universal Satin Photo Paper-914 mm x 30.5 m (36 in x 100 ft)
Q1427A HP Universal Gloss Photo Paper-914 mm x 30.5 m (36 in x 100 ft)
Service & support
UT911E HP Care Pack, Next Business Day Designjet T1200 HD-MFP Hardware Support, 3 years
UT912E HP Care Pack, Next Business Day Designjet T1200 HD-MFP Hardware Support, 4 years
UT913E HP Care Pack, Next Business Day Designjet T1200 HD-MFP Hardware Support, 5 years
UT920E HP Care Pack, 4 Hour Response Time 13x5 Designjet T1200 HD-MFP Hardware Support, 3 years
UT923PE HP Care Pack, Post Warranty Next Business Day Designjet T1200 HD-MFP Hardware Support, 1 year
UT924PE HP Care Pack, Post Warranty Next Business Day Designjet T1200 HD-MFP Hardware Support, 2 years
UT927PE HP Care Pack, Post Warranty 4 Hour Response Time 13x5 Designjet T1200 HD-MFP Support, 1 year
Count on dependable support to create the best image possible. We can help you enhance your printing and
imaging environment, protect your IT investment, and grow your business—with expert support that’s affordable,
personal, and tailored to your needs through HP Care Pack Services.
For more information, please visit
For more HP Large Format Media substrates and sizes please visit us online at: http://www.hp.com/go/designjet/supplies
© Copyright 2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
4AA0-4603EEE Published in EMEA June 2013
