NOTE: If the paper has jammed, it is recommended that you reinsert the printheads and initiate the
realignment procedure by pressing
, then , then Image Quality Maintenance > Align
printheads.
CAUTION: Do not use transparent or semi-transparent paper to align the printheads.
Reinsert printheads procedure
1. If the realignment process is running and the wrong paper is loaded, press on the front panel.
CAUTION: Do not print if the realignment process has been canceled. You can restart the
alignment by pressing
, then , then Image Quality Maintenance > Align
printheads.
2. Load the paper you wish to use, see Paper handling on page 38. You can use a roll that is at least
610 mm (24 in) wide or a cut sheet that is A2 landscape or larger.
CAUTION: Do not use transparent or semi-transparent paper to align the printheads.
3. Remove and re-insert all the printheads, see Remove a printhead on page 129 and Insert a
printhead on page 132. This starts the printhead alignment procedure.
4. Ensure the window is closed, as a strong light source near the printer during printhead
realignment can affect alignment.
5. The process takes about six minutes. Wait until the front-panel display shows the process complete
before using the printer.
NOTE: The printer prints a calibration image. Do not worry about the image. The front-panel
display shows any errors in the process.
Image Quality Maintenance menu procedure
1. Load the paper you wish to use, see Paper handling on page 38. You can use a roll or cut sheet,
however, it must be A3 landscape or larger (420 by 297 mm).
CAUTION: Do not use transparent or semi-transparent paper to align the printheads.
2.
From the front panel, press
, then , then Image Quality Maintenance > Align
printheads. The printer checks to see if it has enough paper to run the realignment.
ENWW
Align the printheads
187
