HP Designjet T920 ePrinter series
Technical specifications
Print
Line Drawings
21 sec/page, 120 A1 prints per hour
Print resolution
Up to 2400 x 1200 optimised dpi from 1200 x 1200 input dpi and Optimisation
For Photo Paper selected
Margins (top x bottom x left x right)
Roll: 5 x 5 x 5 x 5 mm
Sheet: 5 x 22 x 5 x 5 mm
Technology
HP Thermal Inkjet
Ink types
Dye-based (C, G, M, pK, Y); pigment-based (mK)
Ink colours
6 (1 each cyan, grey, magenta, matte black, photo black, yellow)
Ink drop
6 pl (C, M, Y, G, pK); 9 pl (mK)
Print cartridge volume delivered
HP 727 Ink Cartridge: cyan, grey, magenta, matte black, photo black, yellow (130
ml); matte black (69 ml); cyan, grey, magenta, photo black, yellow (40 ml)
Print head nozzles
9632
Print heads
1 (cyan, grey, magenta, matte black, photo black, yellow)
Line accuracy
+/- 0.1%
Minimum line width
0.02 mm (HP-GL/2 addressable)
Guaranteed minimum line width
0.07 mm (ISO/IEC 13660:2001(E))
Maximum print length
91 m
Maximum print weight
11.9 kg
Maximum optical density
6 L* min/2.15 D
Media
Handling
Input: automatic front-loading roll feed; sheet feed; Output: integrated output
stacking tray (from A4 to AO, with up to 50 A1-size capacity); basket; automatic
cutter
Types
Bond and coated paper (bond, coated, heavyweight coated, super heavyweight
plus matte, coloured), technical paper (natural tracing, translucent bond,
vellum), film (clear, matte, polyester), photographic paper (satin, gloss,
semi-gloss, matte, high-gloss), backlit, self-adhesive (two-view cling, indoor
paper, polypropylene, vinyl)
Weight
60 to 328 g/m²
Size
210 x 279 to 914 x 1219 mm
Thickness
Up to 0.5 mm (up to 0.6 mm printed to the output stacking tray with manual
mode)
Memory
Standard
32 GB virtual memory
Hard disk
320 GB and front panel job queues available only for CR355A
Connectivity
Interfaces (standard)
Gigabit Ethernet (1000Base-T) (includes an embedded Jetdirect print server)
Print languages (standard)
CR354A: HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4, HP PCL 3 GUI, URF; CR355A:
Adobe® PostScript® 3, Adobe PDF 1.7 Extension Level 3, HP-GL/2, HP-RTL, TIFF,
JPEG, CALS G4, HP PCL 3 GUI, URF;
Drivers included
CR354A: HP-GL/2, HP-RTL drivers for Windows; HP PCL 3 GUI driver for Mac OS
X; CR355A: HP-GL/2, HP-RTL drivers for Windows; PostScript Windows, Linux,
and Mac drivers;
Operating systems compatibility
Windows 8 Professional/Home (32-bit/64-bit); Windows Server 2012; Windows
7 Ultimate/Professional/Home Premium (32-bit/64-bit); Windows Vista
Ultimate/Business/Home Premium (32-bit/64-bit); Windows XP
Professional/Home (32-bit/64-bit); Windows Server 2008 (32-bit/64-bit),
Windows Server 2008 R2, Windows Server 2003 (32-bit/64-bit); Mac OS X
v10.6, v10.7, v10.8; Linux (see hplip.net)
Recommended system requirements
Mac
Mac OS X v10.6: Intel® processor; 1 GB RAM; 5 GB available hard disk space; Mac
OS X v10.7: Intel® Core™ 2 Duo, Core i3, Core i5, Core i7, or Xeon® processor; 2
GB RAM; 7 GB available hard disk space; Mac OS X v10.8: only supported in
specific Mac models, OS X v10.6.8 or later installed, 2 GB RAM; 8 GB available
hard disk space
Windows
Windows XP Professional/Home (SP2 or higher): Intel® Pentium® family or AMD
K6™/Athlon™/Duron™ family (1 GHz); 512 MB RAM; 2 GB available hard disk
space
Environmental ranges
Operating temperature
5 to 40ºC
Storage temperature
-25 to 55ºC
Operating humidity
20 to 80% RH
Storage humidity
0 to 95% RH
Acoustic
Sound Pressure
47 dB(A)
Sound Power
6.5 B(A)
What's in the box
CR354A
HP Designjet T920 914 mm (36-inch) ePrinter; printhead; ink cartridges;
stacking tray; printer stand; spindle; quick reference guide; setup poster; startup
software; power cord
CR355A
HP Designjet T920 914 mm (36-inch) PostScript ePrinter; printhead; ink
cartridges; stacking tray; printer stand; spindle; quick reference guide; setup
poster; startup software; power cord
Dimensions (w x d x h)
Printer
1399 x 916 x 1110 mm
Packaged
1502 x 759 x 775 mm
Weight
Printer
87 kg
Packaged
112.5 kg
Power consumption
Maximum
<120 watts (printing); <260 watts (maximum); <4 watts / <7 watts with
embedded Digital Front End (sleep); 0.1 watts (auto-off); 0 watts (off
hardswitch)
Power requirements
Input voltage (auto ranging): 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz), 4.2
A max (peak current)
Certification
Safety
EU (LVD and EN60950-1 compliant); Russia (GOST)
Electromagnetic
Compliant with Class B requirements: EU (EMC Directive)
Environmental
ENERGY STAR®; WEEE; EU RoHS; REACH; EuP; FEMP
ENERGY STAR
Yes
Warranty
One-year limited warranty. Warranty and support options vary by product,
country and local legal requirements.
Ordering information
Product
CR354A
HP Designjet T920 A0/914mm ePrinter
CR355A
HP Designjet T920 A0/914mm PostScript ePrinter
Accessories
C0E65A
HP Designjet T9x0/Tx500 36-in Spindle
CN538A
HP Designjet 3-in Core Adapter
CQ654B
HP Designjet HD Scanner
Ink supplies
C1Q12A
HP 727 300-ml Matte Black Designjet Ink Cartridge
B3P22A
HP 727 130-ml Matte Black Designjet Ink Cartridge
B3P24A
HP 727 130-ml Gray Designjet Ink Cartridge
B3P23A
HP 727 130-ml Photo Black Designjet Ink Cartridge
B3P21A
HP 727 130-ml Yellow Designjet Ink Cartridge
B3P20A
HP 727 130-ml Magenta Designjet Ink Cartridge
B3P19A
HP 727 130-ml Cyan Designjet Ink Cartridge
C1Q11A
HP 727 69-ml Matte Black Designjet Ink Cartridge
B3P18A
HP 727 40-ml Gray Designjet Ink Cartridge
B3P17A
HP 727 40-ml Photo Black Designjet Ink Cartridge
B3P15A
HP 727 40-ml Yellow Designjet Ink Cartridge
B3P14A
HP 727 40-ml Magenta Designjet Ink Cartridge
B3P13A
HP 727 40-ml Cyan Designjet Ink Cartridge
B3P06A
HP 727 Designjet Printhead
Service & support
U7Y82E - HP 3 year Next Business Day Designjet T920-36in Hardware Support
U7Y83E - HP 4 year Next Business Day Designjet T920-36in HardwareSupport
U7Y84E - HP 5 year Next Business Day Designjet T920-36inHardware Support
U7Y97E - HP 3 year 4-hour 13x5 Designjet T920-36in Hardware Support
U7Z00PE - HP 1 year Post Warranty Next Business Day Designjet T920-36in Hardware Support
U7Z06PE - HP 2 year Post Warranty Next Business Day Designjet T920-36in Hardware Support
U7Z05PE - HP 1 year Post Warranty 4-hour 13x5 Designjet T920-36in Hardware Support. U7Y97E and U7Z05PE not
available in Italy, Poland and MEMA (except for South Africa & Israel).
HP Designjet Support Services offer solutions for business critical environments - installation, extended support and
maintenance, as well as variety of value added services. For more information, please visit hp.com/go/designjet/support.
Use Original HP inks and printheads to experience consistent high quality and reliable performance that enable less
downtime. For more information, visit hp.com/go/OriginalHPinks.
For the entire HP Large Format Printing Materials portfolio, please see globalBMG.com/hp.
For more HP Large Format Media substrates and sizes please visit us online at: http://www.hp.com/go/designjet/supplies
© Copyright 2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
4AA4-6321EEE Published in EMEA March 2014
