HP Designjet T920 Service Manual

Introduction
This service manual contains information necessary to test, maintain, and service the following:
●
HP Designjet T920 ePrinter
●
HP Designjet T920 PostScript ePrinter
●
HP Designjet T1500 ePrinter
●
HP Designjet T1500 PostScript ePrinter
●
HP Designjet T2500 eMultifunction
●
HP Designjet T2500 PostScript eMultifunction
●
HP Designjet T3500 Production eMultifunction
●
HP Designjet T3500 Production PostScript eMultifunction
For information about using these printers, see the user's guide.
Features overview
There are 6 versions of the HP Designjet T920-T1500–T2500–T3500 series:
●
CR354A HP Designjet T920 36-in ePrinter
●
CR355A/B HP Designjet T920 36-in PostScript ePrinter
●
CR356A HP Designjet T1500 36-in ePrinter
●
CR357A/B HP Designjet T1500 36-in PostScript
●
CR358A HP Designjet T2500 eMultifunction
●
CR358A/B HP Designjet T2500 PostScript eMultifunction
●
B9E24A/B HP Designjet T3500 Production eMFP
NOTE: As of August 2013 there are no plans for an upgrade to enable PostScript features from non-
PostScript capabilities.
The different sku features are:
Feature CR354A HP
Designjet T920
36-in ePrinter
CR355A/B HP
Designjet T920
36-in PostScript
ePrinter
CR356A HP
Designjet T1500
36-in ePrinter
CR357A/B HP
Designjet T1500
36-in PostScript
CR358A HP
Designjet T2500
eMultifunction
and CR358A/B
HP Designjet
T2500
PostScript
eMultifunction
B9E24A/B HP
Designjet T3500
Production
eMFP
Paper source One 36-in roll, and single sheets Two 36-in rolls, and single sheets
Paper output Stacker, accepting up to 50 A1 plain-paper sheets, and basket
2 Chapter 1 Printer fundamentals ENWW

HP Designjet T920 Specifications

General

Model	HP Designjet T920
Category	Printer
Print Technology	Thermal Inkjet
Print Resolution	Up to 2400 x 1200 optimized dpi
Hard Disk	320 GB
Dimensions (W x D x H)	1399 x 916 x 1110 mm
Type	Large Format Printer
Print Speed	21 sec/page on A1/D, 120 A1/D prints per hour
Media Types Supported	Bond and coated paper, technical paper, film, photographic paper, self-adhesive
Connectivity	Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi
Line Accuracy	+/- 0.1%
Print Languages	HP-GL/2, HP-RTL, CALS G4, JPEG
Operating Systems Supported	Windows, macOS
Maximum Print Width	914 mm
Roll Width	24 to 36 in (610 to 914 mm)
Media Sizes Supported	210 to 914 mm wide sheets; 279 to 914 mm rolls
