Electrical Parts
Part number Description Cross-reference
T920 T1500 T2500 T3500
1 CR357-67050 Jester plus Riser Jester PCA on page 273
2a CR357-67051 CR359-6
7001
N/A Formatter Power W/ Riser (For
Rev.A models only)
Formatter PCA on page 278
2b CR357-67085 CR359-6
7031
B9E24-670
15
Formatter power w/ Riser and
w/ HDD (for T920, T1500,
T2500 only rev B models only,
for T3500 all (A and B)
Formatter PCA on page 278
3 CR357-67049 B9E24-670
17
Engine PCA Engine PCA on page 277
4 CR357-67048 E-Box Fan E-Box fan on page 271
ENWW Electrical Parts 231
