Get to know the ink tank system
Get to know the HP DeskJet GT 5810 series ink tank system.
Term Denition
Printheads The printheads are the components in the print mechanism that apply ink to the paper. There are two
printheads: a black ink printhead and a tri-color ink printhead. Once the printheads are installed, they
should not be removed from the print carriage.
Printhead latch The printhead latch on the carriage secures the printheads in the carriage. The printhead latch should not
be opened after the printheads are installed and the ink system has primed.
Ink tanks Ink tanks are external ink reservoirs located at the right side of printer. There are four ink tanks. Each ink
tank corresponds to an individual color: black, cyan, magenta, and yellow.
Ink tank caps Ink tank caps are rubber plugs that seal each ink tank.
Ink valve The ink valve switch on the side of the ink tank controls the ow of ink between the tanks and the
printheads. For more information, see Ink valve on page 40
Priming Priming is the process of lling the ink supply tubes that run between the ink tanks and the printheads.
This process occurs when you install new printheads and start the priming process from the control panel.
For more information about priming, see Printhead priming and alignment icons on page 9.
Alignment Alignment is a process of aligning the printheads to improve print quality. For more information about
alignment, see Printhead priming and alignment icons on page 9.
ENWW Get to know the ink tank system 5
