NOTE:
TheDON’TERASElogicaldrivesupportstheQuickRestoreprocess
only and does not host the secondary operating system. If you need to
perform a Quick Restore of your server, see the Quick Restore instructions
inside the Quick Restore DVD. Be sure to back up your user data, and
then use the Quick Restore DVD to restore the server to the factory
default state.
External storage drives
The two MSA30 storage enclosur es for the DL380 G4 9TB are configured
for hardware RAID fault tolerance using the HP Smart Array 6402 RAI D
Controller. The HDDs are hot-pluggable and hot-swappable.
The logical drives are c onfiguredasRAID5volumes,andpartitioned
with four RAID 5 logical partitions. A total of four R AID 5 backup data
partitions, plus one internal, are available for the DPM software.
Table9DL380G4DPStorageServer9TBtwo–MSA30
configurations
Logical
drive
RAID level
Size/allocation
Purpose
Array A
1
RAID 5
2 TB across the array. Backup
data
2
RAID 5
Remaining space across the
array.
Backup
data
Array B
1
RAID 5
2 TB across the array. Backup
data
2
RAID 5
Remaining space across the
array.
Backup
data
1
1
For each array, a hot spare is available.
Default boot sequence
The BIOS s upports the following default boot sequence:
40
Default storage configurations
