HP DreamColor Z24X

Rear Components
Component Function
1
USB 3.0 Downstream
Connectors (side panel)
Connects optional USB devices to the monitor.
2
Master Power Switch Turns off all power to the monitor.
NOTE: Putting the switch in the Off position will yield the
lowest power state for the monitor when not in use.
3
AC Power Connector Connects the AC power cord to the monitor.
4
DisplayPort IN Connects the DisplayPort cable to the monitor.
5
DVI-D Connects the DVI-D cable to the monitor.
6
HDMI Connects an HDMI cable to the monitor.
7
DisplayPort OUT Connects a second monitor.
8
Audio Out Connects headphones or optional HP Speaker Bar to the
monitor.
9
USB 3.0 Upstream
Connector
Connects the USB hub cable to the monitor's USB hub
connector and to a host USB port/hub.
10
USB 3.0 Downstream
Connectors
Connects optional USB devices to the monitor.
Rear Components 7
