HP DX2200 - Page 9

Industrial Standard
Industrial StandardIndustrial Standard
Industrial Standard PCI 2.3 compliant
USB 2.0
Rear Side I/O Ports
Rear Side I/O PortsRear Side I/O Ports
Rear Side I/O Ports 1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 2.0 ports
1 x RJ-45 10/100 port
1 x serial port
1 x parallel port
1 x DB 15 pin analog VGA port
3 x audio ports
On Board I/O Interfaces
On Board I/O InterfacesOn Board I/O Interfaces
On Board I/O Interfaces 1 x ATX power connector
1 x +12V power connector
1 x Floppy connector
1 x Front panel connector, Switch, LED (ON/Flash/OFF)
2 x Fan headers for CPU, chassis, with voltage/fan speed control
1 x ATAPI headers-CD IN
1 x header to support 2 USB 2.0 ports at front side
1 x header to support USB media reader
Board Size
Board SizeBoard Size
Board Size Micro-ATX, PCB Size: 9.6 x 9.0 in (24.38 x 22.86 cm)
4-layer PCB with green color
Additional Features
Additional FeaturesAdditional Features
Additional Features Bootable without keyboard, mouse or monitor
Keyboard/mouse/USB wake up
Support S1, S3, S4 and S5
ACPI status
Hardware monitor capability
CPU fan speed control
Network Interface
Network InterfaceNetwork Interface
Network Interface Integrated Realtek 8100C Fast Ethernet Network Controller
Integrated Realtek 8100C Fast Ethernet Network ControllerIntegrated Realtek 8100C Fast Ethernet Network Controller
Integrated Realtek 8100C Fast Ethernet Network Controller
Hardware Highlights
Hardware HighlightsHardware Highlights
Hardware Highlights PCI interfaces
Features
FeaturesFeatures
Features 10-Mbps and 100-Mbps operation
Intel PRO/1000 GT Gigabit PCI Adapter
Intel PRO/1000 GT Gigabit PCI AdapterIntel PRO/1000 GT Gigabit PCI Adapter
Intel PRO/1000 GT Gigabit PCI Adapter
Hardware Highlights
Hardware HighlightsHardware Highlights
Hardware Highlights PCI interfaces
Features
FeaturesFeatures
Features 10-Mbps, 100-Mbps and 1000-Mbps operation
Wireless
WirelessWireless
Wireless Wireless A+G PCI Card (full height bracket)
Power Supply
Power SupplyPower Supply
Power Supply ATX Power Supply – Passive PFC/non-PFC with a 115v/230v line switch
Passive Power Factor Correction (PFC) – with line switch set to 230V – No PFC in 115V line switch
position
90 to 140VAC, or 180 to 264VAC operating voltage range
100 to 127VAC, or 200 to 240VAC rated voltage range
50–60 Hz rated line frequency
47–63 Hz operating line frequency range
250 watt maximum rated power
80-mm power supply fan – variable speed for optimum acoustics
QuickSpecs
HP Compaq dx2200 Microtower Business PC
HP Compaq dx2200 Microtower Business PCHP Compaq dx2200 Microtower Business PC
HP Compaq dx2200 Microtower Business PC
System Details
DA - 12426 North America — Version 14 — August 16, 2006 Page 9
