Rear Side I/O Ports
• 1 x PS/2 keyboard port
• 1 x PS/2 mouse port
• 6x USB 2.0 ports
• 1 x RJ-45 10/100/1000 port
• 1 x serial port
• 1 x parallel port
• 1 x DB 15 pin analog VGA port
• 3 x audio ports
On Board I/O Interfaces
• 1 x ATX power connector
• 1 x +12V power connector
• 1 x Floppy connector
• 1 x Front panel connector, Switch, LED (ON/Flash/OFF)
• 2 x Fan headers for CPU, chassis, with voltage/fan speed control
• 1 x ATAPI headers-CD IN
• 1 x header to support 2 USB 2.0 ports at front side
Board Size
• Micro-ATX,
Additional Features
• Support S3, S4 and S5
• ACPI status
• Hardware monitor capability
• CPU fan speed control
• Wake on LAN
Integrated Realtek RTL8110SX Network Connection
Hardware Highlights
• Realtek RTL8110SX Platform LAN Connect device
• 10/100/1000 mbps
• IEEE 802.3 10BASE-T compliant physical layer interface
• IEEE 802.3u Auto-Negotiation and 100BASE-TX support
• 10BASE-T auto-polarity correction
• 1:1 transmit transformer ratio support
• Low power (300 mW) typical in active transmit mode
• Reduced power(less than 50 mW) in "unplugged mode"
• Automatic detection of "unplugged mode"
Network Interface
Features
• ACPI support
• Magic Packet filtering for Wake on LAN support
• Automatic detection of "unplugged mode"
• Low power (less than 300 mW in active transmit mode)
• Platform LAN connect interface support
• Low power 3.3 V device
Power Supply
• ATX Power Supply - non-PFC
• 220 to 230VAC input voltage range
• 50-60 Hz rated line frequency
• 300 watt maximum power
• power supply fan
