QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Optical Storage
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 24
Temperature
41° to 122° F (5° to 50° C)
Relative Humidity
10% to 90%
Environmental
(all conditions
non-condensing)
Maximum Wet Bulb
Temperature
86° F (30° C)
Height
5.25-inch, half-height, tray-load
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc capacity
Single layer: Up to 4.7 GB (6 times capacity of CD-ROM)
Double layer: Up to 8.5 GB (12 times capacity of CD-ROM)
Dimensions (W x H x
D)
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
Weight (max)
2.6 lb (1.2 kg)
CD-R
Up to 48X
Write speeds
CD-RW
Up to 32X
DVD+R/-R/+RW/
-RW/+R DL /-R DL
Up to 8X
DVD-ROM
Up to 16X
CD-ROM, CD-R
Up to 48X
Read speeds
CD-RW
Up to 32X
Random
DVD: < 140 ms (typical), CD: < 125 ms
(typical)
Access times
(typical reads, including
setting)
Full Stroke
DVD: < 250 ms (typical), CD: < 210 ms
(typical)
Source
SATA DC power receptacle
DC Power
Requirement
5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p
Power
DC Current
5 VDC (<1000 mA typical, < 1600 mA
maximum)
12 VDC (< 600 mA typical, < 1400 mA
maximum)
Temperature
41° to 122° F (5° to 50° C)
Relative Humidity
10% to 90%
SATA Combo Drive
Environmental
(all conditions
non-condensing)
Maximum Wet Bulb
Temperature
86° F (30° C)
Height
5.25-inch, half-height, tray-load
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc capacity
8.5 GB DL or 4.7 GB standard
HP SATA SuperMulti
LightScribe DVD
Writer Drive
Dimensions (W x H x
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
