QuickSpecs
HP Compaq dx2480 Microtower Business PC
System Details
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 8
Operating
10% to 90% (non-condensing at ambient)
Relative Humidity
Non-operating
5% to 95% (non-condensing at ambient)
Operating
10,000 ft (3048 m)
Maximum Altitude
(unpressurized)
Non-operating
30,000 ft (9000 m)
NOTE: Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 10,000 ft (3000
m) above sea level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The
upper limit may be limited by the type and number of options installed.
Processor
Socket T; LGA775 industry standard Micro ATX form factor
Support Intel Pentium Dual Core, Core 2 Duo or Quad core, Celeron
4xx or Dual Core
PWM
ON NCP5387 – 3 Phase
Chipset
Intel G33 Express
Intel I/O Controller Hub 9 (ICH9)
Super I/O
ITE 8718F
Front Side Bus
Frequency
800/1066/1333 MHz
Memory
DDR2 SDRAM
4 DIMM slots
Clock Generator
RMT875T-605
Integrated Graphics
Intel Graphics Media Accelerator (GMA) 3100
Audio
Realtek ALC883 HD Audio compatible codec with eight channel audio
LOM
Realtek RTL8111C GbE Ethernet controller
Storage
Four Serial ATA interfaces
Expansion Slots
2 x PCI 2.3 slot
1 x PCI Express x1 slots
1 x PCI Express x16 slot
BIOS
Award Core 6
Industrial Standard
PCI 2.3 compliant
USB 2.0
Rear Side I/O Ports
1 x PS/2 Keyboard port
1 x PS/2 mouse port
6 x USB 2.0 ports
1 x RJ-45 10/100/1000 port
1 x D-sub 15 pin analog VGA port
3 x audio ports
System Board
On Board I/O
Interfaces
1 x ATX power connector
1 x +12V power connector
1 x Floppy connector
1 x Front panel connector, Switch, LED (ON/Flash/OFF)
2 x Fan headers for CPU, chassis, with voltage/fan speed control
3 x Internal USB header
1 x header to support 2 front (Headphone/Mic) audio ports
